Weigh Shark Belt Scale

Weigh Shark Belt Scales and Products available Nationwide

MCR Technologies Group provides six standard models to choose from to best suit your requirements. The Weigh Shark scales are easy to install and to calibrate. Standard model scales are always in stock and can be shipped within 24 hours. There are many additional products available to help support your different applications.

The Weigh Shark Standard Mount belt scale is designed to mount with CEMA troughing idlers.

The Weigh Shark WING C is designed to mount on the C-Channel frame support of the main conveyor.

The Weigh Shark WING B is designed to mount on side discharge conveyors with tube frame construction.

The Weigh Shark CIT is designed for conveyors with channel mount insert idlers.

The Weigh Shark Garland belt scale is designed to use with 3-5 roller idlers that are free hanging from a chain or cable.

The kW Electric belt scale is designed to be used with motors.

Weigh Shark Belt Scales include the following parts.

Load Cell Assemblies–- Built with solid steel construction with durable powder coating for protection, includes 32 Idler Shims.

Heavy Duty Speed Sensor- Built with solid steel construction with durable powder coating for protection, with solid stainless-steel wheel.

Weigh Shark Integrator (WS1) - NEMA 4X Rated

Standard Features:

  • Large Graphical Display
  • 4 Digital Inputs
  • 4 Digital Outputs
  • 0-20mA/4-20mA (16bit) Current Loop
  • Ethernet—HTTP Web Server ready
  • RS 232 and RS 485 Serial Ports
  • Modbus TCP via Ethernet
  • Modbus RTU via RS 485 Port
  • Accepts 110/220 Vac and12/24 Vdc.

Weigh Shark Integrator (WS2)

Hardware Features:

  • 7" Color Touch Screen
  • Dual 32bit processors
  • 3-Port Ethernet switch
  • USB Host for Flash Drive
  • 1 - RS-232 Port
  • 1 - RS-485 port
  • 1 - 4-20mA Current Loop
  • 4 - Digital Inputs
  • 4 - Digital Outputs
  • 3 - Expandable I/O ports

Software Features:

  • 4 - Language Options
  • 5 - Units of Measure Options
  • Internal Speed Mode
  • Current Loop Simulator
  • Ethernet protocols: HTTP Server, MODBUS TCP/IP, MQTT
  • Serial Port protocols: Angle Sensor, MODBUS/RTU, Printer,  Scoreboard Sign
  • 8 - Weight Accumulators
  • In-Field Software Updates

Additional Information

Two Year Warranty on Parts – Refer to manual for complete warranty information.
Belt scales are available in stainless steel. Single Idler scale as standard, multi-idler scales available.
Standard Load Cells are Temperature Compensated 14 F to 122 F (-10 C to 50 C)
Optional Low Temp Stainless Load Cells are Temperature Compensated - 60 F to 125 F (-51 C to 51 C)

Belt Scale
Application Form
Project Details

Note—When used with portable equipment the accuracy could decrease based on the type of load and installation.
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Weigh Shark belt scale

Weigh Shark Belt Scale Overview

Download

Weigh Shark Belt Scale Overview

Download

Garland Belt Scale
Overview

Download

Weigh Shark HD Scale Overview

Download

Weigh Shark Wing Scale Overview

Download

Channel Insert Scale

Download

MCR-Sales-Brochure-2024-WS2

Download

Weigh Shark belt Optional ADd-Ons

Blending Systems

Download

Remote Display

Download

Magnetic Encoder

Download

Marquee Signs

Download

Calibration Kit
For Wing Idlers

Download

Weigh Scale Ticket Printer

Download

Metal Control Box

Download

7.5 Inch Speed Sensor Tube Design

Download

Shark 2 Control Box

Download

Manuals and Applications

Weigh Shark
Manual

Download

Weigh Shark
Wing B & C

Download

Weigh Shark
Garland Manual

Download

HD Scale
Manual

Download

Remote Display
Manual

Download

Blending System
Manual

Download

CIT Manual

Download

Marquee
Manual

Download

Truck Load Out
Manual

Download

Modbus
Manual

Download

Zero-Cutoff
Manual

Download

Weigh Shark
Application

Download

WS2 Installation Manual

Download
